Caracteristicas:
-Wi-Fi 2x2 de alta eficiencia 6
Banda de 5 GHz 2x2 MU-MIMO y OFDMA con velocidad de radio de 1.2 Gbps
-MIMO 2x2 de banda de 2,4 GHz con velocidad de radio de 300 Mbps
Gigabit Ethernet, alimentado con 802.3af PoE (inyector PoE no incluido)
-Compatible con cubiertas UAP-nanoHD y soporte de montaje empotrado
Especificaciones:
Mechanical
Dimensions: Ø160 x 32.65 mm (Ø6.3 x 1.3")
Weight: Without Mount: 300 g (10.6 oz) // With Mount: 315 g (11.1 oz)
Enclosure Characteristics: Polycarbonate 110 and ADC12 Die Casting
Mounting Characteristics: Polycarbonate, SGCC Steel
Hardware
Processor Specs: 880 MHz MIPS 1004 KEc
Memory Information: 256 MB
Management Interface: Ethernet In-Band
Networking Interface: (1) 10/100/1000 Mbps Ethernet RJ45
Buttons: Factory Reset
LEDs: White/Blue
Power Method: 802.3af PoE, Passive PoE (48V)
Power Supply: 802.3af PoE; 48V, 0.32A PoE Adapter (Not Included)
Supported Voltage Range: 44 to 57VDC
Max. Power Consumption: 12W
Max. TX Power: 23 dBm
MIMO: 2 x 2
Throughput Speeds: 2.4GHz - 300Mbps // 5GHz - 1201Mbps
Operating Temperature: -30 to 60° C (-22 to 140° F)
Operating Humidity: 5 - 95% Noncondensing
Certifications: CE, FCC, IC
Software
Wi-Fi Standards: 802.11a/b/g // Wi-Fi 4/Wi-Fi 5/Wi-Fi 6
Wireless Security: WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3*) *Supported With Upcoming Controller Versions
BSSID: 8 per Radio
VLAN: 802.1Q
Advanced QoS: Per-User Rate Limiting
Guest Trafc Isolation: Supported
Concurrent Clients: 300+
Supported Data Rates (Mbps)
802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n (Wi-Fi 4): 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)
802.11b: 1, 2, 5.5, 11 Mbps
802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11ac (Wi-Fi 5): 6.5 Mbps to 866.7 Mbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80)
802.11ax (Wi-Fi 6): 6.3 Mbps to 1.2 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80)
